| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Voltage Rating |
The Carlo Gavazzi GSB633PC16 is a supplementary circuit protector designed for applications where branch circuit protection is already provided. This 3-pole miniature circuit breaker operates with a thermal magnetic tripping mechanism and is UL1077 recognized.
Key electrical specifications include a rated current of 16A and a voltage rating of 480V. It features a C trip characteristic, suitable for protecting circuits against overload and short-circuit currents with a rated short-circuit breaking capacity of 5kA at 230V.
Designed for easy installation, the GSB633PC16 utilizes DIN rail mounting. It is equipped with a lever actuator for operation. This breaker is part of the GSB63 series, offering a range of pole configurations and current ratings up to 63A.
Environmental compliance includes RoHS3 compliance, an MSL of 1, and REACH unaffected status, though these are noted as low confidence due to lack of verification.
16 A.
480 V.
3 poles.
C-curve.
5 kA.
DIN Rail.
UL1077.
