| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
770 pcs
|
770 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination |
The GRPB041VWVN-RC is a 4-position single row male pin header manufactured by Sullins Connector Solutions. This header features a 1.27mm pitch, making it suitable for compact board-to-board or cable interconnects. The contacts are made of brass with a gold flash finish, housed in a PA9T nylon insulator rated UL94 V-0 for flammability. Each contact can handle up to 1A of current, with an operating temperature range of -40°C to 105°C. The header is unshrouded with a through hole solder termination, providing reliable mechanical and electrical connections. The overall contact length is 0.248 inches (6.30mm), with a mating pin length of 3.00mm and an insulation height of 1.00mm, allowing for standard insertion into printed circuit boards.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.28 | $0.28 |
| 10+ | $0.24 | $0.24 |
| 100+ | $0.20 | $0.20 |
| 500+ | $0.18 | $0.18 |
| 1,000+ | $0.17 | $0.17 |
| 5,000+ | $0.16 | $0.16 |
| 10,000+ | $0.15 | $0.15 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The GRPB041VWVN-RC has 4 positions.
The pitch is 1.27mm (0.050 inches).
The current rating is 1A per contact.
It uses through hole mounting with solder termination.
The insulator is made of Polyamide (PA9T, Nylon 9T) with UL94 V-0 flammability rating.
Contacts are made of brass with gold flash finish overall.
The operating temperature range is -40°C to 105°C.
