| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Input Frequency | |
| Medical Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Overload Protection | |
| Power (Watts) | |
| Temperature Coefficient | |
| Type | |
| Voltage |
The SL Power Electronics GPFM115-12G is an open-frame AC/DC converter designed for various applications, including medical. It provides a continuous output power of 80W with natural convection, which can be boosted to 115W with forced air cooling. The unit accepts a universal input voltage range of 85 to 264 VAC and delivers a stable 12VDC output.
Key features include adjustable output voltage, power factor correction (PFC), remote sense capability, and built-in EMI filtering for compliance. The converter operates within a temperature range of 0°C to 50°C and offers protection against overload and overvoltage conditions. Its compact dimensions of 133.4mm x 83.8mm x 38.1mm make it suitable for integration into systems requiring efficient power conversion.
This model also includes a 12VDC fan output and a power fail signal that triggers before output voltage drops below nominal. The transient response time is typically 500 μs for a 50% load step change. The GPFM115-12G is designed for chassis mounting, offering flexibility in system design.
The main output voltage is 12 VDC.
The continuous output power is 80W with natural convection and 115W with forced convection.
The input voltage range is 85 to 264 VAC.
The operating temperature range is 0°C to 50°C.
Yes, it is fully protected against short circuit and output overload with a cycling power limit.
The dimensions are 133.4mm (Length) x 83.8mm (Width) x 38.1mm (Height).
The typical transient response time for a 50% load step change is 500 μs.
