The GPFC125BG from SL Power Electronics is a 125-watt open-frame AC/DC power supply designed for commercial ITE applications. It accepts a universal input voltage range of 90 to 264 VAC at 47-63 Hz.
This converter provides four distinct output voltages: 5V at 9A, 12V at 3.5A, 12V at 2.5A, and -5V at 300mA. It boasts an efficiency of 72% to 85% and includes features such as Power Factor Correction (PFC) and Remote Sense on the primary output.
The unit is chassis mountable and operates within a temperature range of 0°C to 50°C. It is protected against short circuit and output overload conditions, with total output power limited to approximately 150 Watts. The dimensions are 152.4mm x 88.9mm x 38.1mm.
Compliance includes CE approval. The product is RoHS3 compliant and has an MSL rating of 1.
90-264 VAC.
0°C to 50°C.
Chassis mount.
125W with 150LFM forced air cooling, 50W convection cooled.
72% to 85% at full rated load.
Yes, active PFC with 0.99 typical, 0.96 minimum.
5V, 12V, 12V, and -5V.
