The SL Power Electronics GPFC110-5G is a 110 Watt Global Performance Switcher designed for commercial applications. This open frame AC/DC converter operates with a universal input voltage range of 85-264 VAC.
Key electrical specifications include a nominal output voltage of 5.1VDC and a maximum output current of 11A, providing up to 75W of power via convection cooling or 110W with forced air. The unit offers features such as adjustable output voltage (±5%), remote sense capability, and a power fail signal. It meets stringent EMI/EMC requirements including EN55022 Class B and FCC Class B, and is power factor corrected to IEC 1000-3-2 Class A.
Mechanically, the GPFC110-5G has a compact size of 6.30" x 3.75" x 1.62" (160.0mm x 95.3mm x 41.2mm), designed for chassis mounting and meeting 1U height requirements. The operating temperature range is 0°C to 50°C with derating. Safety approvals include CE, cURus, and TUV.
This power supply is suitable for ITE (Commercial) applications and comes with a 2-year warranty. A RoHS compliant model is available.
The GPFC110-5G has a nominal output voltage of 5.1VDC and a maximum output current of 11A.
The GPFC110-5G provides 75W via convection cooling and up to 110W with forced air cooling.
The GPFC110-5G accepts a universal input voltage range of 85 to 264 VAC.
The dimensions of the GPFC110-5G are 160.0mm x 95.3mm x 41.2mm (6.30" L x 3.75" W x 1.62" H).
The operating temperature range for the GPFC110-5G is 0°C to 50°C, with derating.
The GPFC110-5G is approved by CE, cURus, and TUV.
Yes, the GPFC110-5G meets EMI/EMC requirements including EN55022 Class B and FCC Class B.
