The SL Power Electronics GPFC110-48G is an open frame AC/DC power supply designed for commercial ITE applications. It provides a 48VDC output and can deliver up to 75W in convection cooling or 110W with forced air.
Key electrical features include a wide input voltage range of 85-264 VAC and power factor correction to IEC 1000-3-2 Class A standards. The unit offers a 25 ms hold-up time and includes protections such as short circuit and overvoltage protection. Output noise is specified at 0.5% rms.
Mechanically, the power supply measures 6.30" x 3.75" x 1.62" and is designed for chassis mounting. It operates within a temperature range of 0°C to 50°C with derating. Compliance includes EMI standards like CISPR 22 and FCC Class B, along with approvals from CE, cURus, TUV, and UL.
Additional features include remote sense capability and a power fail signal. A RoHS3 compliant model is available.
The main output voltage is 48 VDC.
The maximum output current is 1.7 A.
The output power is 75 W with convection cooling and 110 W with fan cooling.
The operating temperature range is 0°C to 50°C with derating.
The dimensions are 160.0mm x 95.3mm x 41.2mm.
Yes, it is power factor corrected to IEC 1000-3-2 Class A.
It complies with CISPR 22 and FCC Class B for EMI, and EN55022 Class B for conducted emissions.
