The SL Power Electronics GPFC110-24G is a versatile AC/DC power supply designed for commercial ITE applications. This open frame unit provides a stable 24VDC output with a maximum current of 3.4A, delivering 75W of power under convection cooling and up to 110W with forced air.
Featuring a wide input voltage range of 85-264 VAC and a frequency of 47-63 Hz, the GPFC110-24G ensures global compatibility. It boasts key electrical specifications including 2% total regulation and 2% load regulation, along with low output noise of 0.5% rms. The unit includes essential protection features such as overload and short circuit protection, and overvoltage protection.
Designed for easy integration, the GPFC110-24G has a compact chassis mount form factor with dimensions of 160.0mm x 95.3mm x 41.2mm. It meets stringent EMI/EMC requirements, including CISPR 22 and FCC Class B, and carries safety approvals from CE, cURus, and TUV. The power supply also features remote sense capability for precise voltage delivery and operates within a temperature range of 0°C to 50°C with derating.
85-264 Vac.
160.0 mm x 95.3 mm x 41.2 mm (6.30" x 3.75" x 1.62").
0°C to 50°C with derating.
75 W under convection cooling, 110 W with forced air.
UL1950, IEC950, CSA 22.2 No. 950, CE, cURus, TUV.
25 ms minimum at full load under nominal line (115 Vac).
2-year warranty.
