The SL Power Electronics GPC225-24 is a 225-watt global performance switcher designed for ITE (Commercial) applications. It operates with a wide-range AC input from 85 to 264 Vac and offers an efficiency of 70% at full rated load.
This open-frame converter features chassis mounting and provides 225W of output power, with a peak rating of 250W for short durations. It includes essential protections such as overload, short circuit, and thermal shutdown. The unit also offers features like adjustable output voltage (±5%) and remote sense capabilities.
Designed for reliability, the GPC225-24 operates within a temperature range of 0 to 50 °C, with derating applied above 50 °C. It meets conducted emissions standards including FCC Class B and CISPR 22 Class B, and complies with static discharge requirements.
Key specifications include a hold-up time of 20 ms minimum, an input current of 5.5 A at 120 Vac, and a temperature coefficient of 0.03%/°C. The dimensions are 228.6mm x 127.0mm x 63.5mm.
The input voltage range is 85-264 Vac, 47-63 Hz single phase.
The operating temperature range is 0°C to 50°C at full rated output power, with derating of 2.5% per °C above 50°C.
It delivers 175 W convection, 225 W with 26 cfm forced air, and 250 W peak (60 s max, 10% duty cycle).
Overload protection is cycling type power limit, overvoltage protection is 124% typical, and thermal shutdown is provided.
Hold-up time is 20 ms minimum from loss of AC input at full load, nominal line (115 Vac).
The dimensions are 228.6 mm (9.00") length, 127.0 mm (5.00") width, and 63.5 mm (2.50") height.
Yes, the output voltage can be adjusted ±5% using the built-in potentiometer.
