The Bel Power Solutions GP3040-9R is an enclosed, conformal coated DC-DC converter with a power rating of 187W. It is designed for chassis mounting and offers a 15V output voltage, delivering up to 17.8A. This converter operates efficiently at 88.5% and is suitable for demanding environments, including ITE (Commercial) and Railway applications.
With a wide operating temperature range of -40°C to 71°C, the GP3040-9R provides reliable performance. Its dimensions are 171.0mm in length, 111.0mm in width, and 19.8mm in height. The unit is safety-approved by agencies including CE, CSA, EN, IEC, TUV, and UL, ensuring compliance with industry standards.
The datasheet indicates availability of RoHS lead-free-solder and lead-solder-exempted products. It also mentions wide input voltage ranges up to 154 VDC and isolated outputs up to 96 V, with very high efficiency up to 90%. The converter features a slim, fully enclosed case and is suitable for rugged environments.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The GP3040-9R provides 187W of power.
The output voltage is 15V.
The efficiency is 88.5%.
The operating temperature range is -40°C to 71°C.
The dimensions are 171.0mm x 111.0mm x 19.8mm.
It is suitable for ITE (Commercial) and Railway applications.
It is approved by CE, CSA, EN, IEC, TUV, and UL.
