| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
160 pcs
|
160 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Material | |
| Features | |
| LED Color | |
| Lead Style | |
| Mounting Type | |
| Number of Ports | |
| Number of Positions | |
| Number of Rows | |
| Orientation | |
| Shielding | |
| Tab Direction | |
| Termination | |
| Termination Style |
The Kycon GMX-SMT2-S2-1010TR is a surface mount modular connector jack from the GMX series. It features 10 positions configured as 10P10C (RJ50) with a single port. The connector is shielded to reduce electromagnetic interference and includes a board lock for secure attachment to the PCB. The termination style is solder, with a 90° right angle orientation and tab direction downward. The contact material is phosphor bronze with a gold finish, ensuring reliable electrical connections over repeated mating cycles. This component is RoHS3 compliant (unverified) and has an MSL rating of Level 1 (unlimited). It does not include an integrated LED indicator. This jack is suitable for applications requiring a compact, shielded RJ50 connection in surface mount designs.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.96 | $2.96 |
| 10+ | $2.52 | $2.52 |
| 25+ | $2.36 | $2.36 |
| 50+ | $2.25 | $2.25 |
| 130+ | $2.10 | $2.10 |
| 260+ | $2.00 | $2.00 |
| 390+ | $1.94 | $1.94 |
| 650+ | $1.87 | $1.87 |
| 910+ | $1.83 | $1.83 |
| 1,300+ | $1.78 | $1.78 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
10 positions configured as 10P10C (RJ50).
Surface mount (SMT).
90° angle (right angle) with tab down.
Yes, it is shielded.
Gold finish on phosphor bronze contacts.
Yes, it includes a board lock feature.
MSL Level 1 (unlimited).
