The Carlo Gavazzi GMS-32S-8A is a manual motor starter designed for efficient motor control and protection. It features a 32A frame size and is rated for an operational current of 8A, with a range of 5-8A.
This starter operates at up to 600VAC and includes Class 10 overload trip characteristics for reliable motor protection. It has a short-circuit current rating of 10kA at 460V. The unit is designed with a compact 45mm width for space-saving installations and supports DIN rail or screw mounting.
Key features include phase failure protection, wide ambient temperature compensation, and finger-safe terminals. The GMS series fulfills the international standard IEC 60947 and can be used as a Manual Motor Starter in Group Installations according to UL508.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operational current range for the Carlo Gavazzi GMS-32S-8A is 5-8 Amps.
The Carlo Gavazzi GMS-32S-8A has a voltage rating of 600VAC.
The Carlo Gavazzi GMS-32S-8A features Class 10 overload trip characteristics.
The short-circuit current rating for the GMS-32S at 460V is 10kA.
The width of the Carlo Gavazzi GMS-32S manual motor starter is 45mm.
