The CINCON EC6A27 is a compact switching power supply designed for ITE (Commercial) applications. It delivers 5W of power with a single 3.3V output and a maximum current of 1.5A. The input voltage range is from 36V to 72V DC.
This power supply operates efficiently at 76% and offers a wide operating temperature range of -40°C to 100°C with derating. It provides 1.5 kV of isolation voltage and is housed in a 24-DIP Module, 14 Leads package, suitable for through-hole mounting. The dimensions are 31.8mm x 20.3mm x 10.2mm.
Compliance includes RoHS3 and REACH Unaffected status. The product is listed as Active.
The output voltage is 3.3V.
The maximum output current is 1.5A.
The input voltage range is 36V to 72V DC.
The operating temperature range is -40°C to 100°C (With Derating).
The RoHS status is ROHS3 Compliant.
The REACH status is REACH Unaffected.
The Moisture Sensitivity Level is 1 (Unlimited).
