| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
133 pcs
|
133 pcs | On Request | 1 | On Request | On Request | 0450 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Breaking Capacity @ Rated Voltage | |
| Current Rating (Amps) | |
| Fuse Type | |
| Melting I²t | |
| Mounting Type | |
| Response Time | |
| Tape & Reel | |
| Termination Style | |
| Voltage Rating |
The GMA-6A is a fast-acting glass cartridge fuse from Eaton's Bussmann series, designed for overcurrent protection in low-voltage AC circuits. It is rated for 6A continuous current at 125V AC and offers a high interrupting capacity of 10kA at rated voltage, ensuring reliable fault clearing.
Key electrical characteristics include a typical DC cold resistance of 0.017 Ω, a typical pre-arcing melting I²t of 45 A²s, and a maximum voltage drop of 180 mV at rated current. The fast blow response time provides rapid protection for sensitive components.
The fuse is housed in a standard 5mm x 20mm glass tube with nickel-plated brass endcaps, requiring a compatible fuse holder for installation. It is approved by CSA, PSE, and UL, meeting global safety standards for industrial and commercial applications.
| Qty | Low | High |
|---|---|---|
| 50+ | $1.47 | $1.47 |
| 300+ | $1.41 | $1.41 |
| 2,000+ | $1.36 | $1.36 |
| 3,000+ | $1.30 | $1.30 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The GMA-6A is rated for 6 A continuous current.
The fuse is rated for 125 V AC.
The breaking capacity is 10 kA at 125 V AC.
It is a fast blow (fast-acting) fuse.
The fuse comes in a standard 5 mm x 20 mm cartridge package.
The typical pre-arcing I²t is 45 A²s.
It is approved by CSA, PSE, and UL.
