| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Frequency | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Power (Watts) | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
The GLD150-24 from SL Power Electronics is a 150W open-frame AC/DC power supply designed for medical applications. It operates with a universal input voltage range of 85-264 Vac and provides a single 24V output.
Key electrical specifications include an efficiency of at least 80% at full load with 230 Vac input, and a maximum input current of 2.8A. The unit offers output regulation of 2% and load regulation of 2%. It is protected against short circuits and overloads.
This power supply features built-in EMI filtering to meet EMC requirements and includes Power Factor Correction (PFC) compliant to IEC 1000-3-2. It also supports remote sense functionality and has an adjustable output voltage of +/- 5%. The dimensions are 177.8mm x 114.3mm x 43.2mm, making it suitable for chassis mounting.
Compliance includes CE, cURus, and TUV certifications, along with meeting IEC601-1 standards for medical equipment. It operates within a temperature range of 0°C to 50°C.
The GLD150-24 accepts a universal input of 85-264 Vac at 47-63 Hz, single phase.
The GLD150-24 provides a 24V output at 6.2A.
The GLD150-24 delivers 150W with convection cooling and 180W with fan cooling.
The operating temperature range is 0°C to 50°C.
The GLD150-24 measures 177.8mm x 114.3mm x 43.2mm (7.00" x 4.50" x 1.70").
The GLD150-24 includes built-in EMI filtering to meet IEC601-1 and conducted emissions to EN55011 Class B and FCC Class B.
