The SL Power Electronics GLD140D is a 140 Watt multiple output AC/DC converter with an open-frame configuration. It is designed for medical applications and operates from a universal input voltage range of 90-264 VAC.
Key electrical specifications include a continuous output power of 140W with convection cooling (180W with forced air), and an efficiency rating of 73-85%. The unit offers multiple outputs: 5VDC @ 16A, 24VDC @ 4A, 12VDC @ 4A, and -12VDC @ 0.75A. It incorporates active power factor correction to meet IEC 1000-3-2 Class A standards and provides overload and short circuit protection.
This converter features a compact size of 8.50" x 4.50" x 1.95" and is suitable for chassis mounting. It operates within a temperature range of 0°C to 50°C. The GLD140D also includes features such as adjustable output voltage (±5%), remote sense on V1 and V2, and overvoltage protection on V1, V2, and V3 outputs. It is approved to UL2601, IEC601-1, CSA 22.2 No. 601.1-M90, and EN60601 standards, and is CE marked.
90-264 VAC.
0°C to 50°C.
5V@16A, 24V@4A, 12V@4A, [email protected].
140W continuous with convection cooling, 180W with 150 LFM forced air.
73-85% at full rated load, nominal input.
26 ms total, with 16 ms minimum from loss of AC input to power fail signal.
Chassis mount, open frame.
