| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
This GLC65D AC/DC converter from SL Power Electronics is designed for commercial ITE applications and offers a total continuous output power of 60W, with a peak rating of 75W for short durations. It operates with a universal input voltage range of 90-264 VAC, making it suitable for global use.
The converter features three outputs: 5V at 7A, 24V at 1.5A, and -12V at 2.5A. It has an efficiency of at least 80% and is built with an open frame construction for chassis mounting. The dimensions are 127.0mm x 76.2mm x 31.8mm.
Key electrical specifications include a holdup time of 20ms at 65W load from 120 VAC input, output noise of 0.5% RMS / 1% pk-pk, and a typical transient response time of 500μs for a 50% load step. Overload and short circuit protection are included, along with overvoltage protection. The operating temperature range is 0°C to 50°C.
The GLC65D has three output voltages: 5V, 24V, and -12V.
The output currents are 7A for 5V, 1.5A for 24V, and 2.5A for -12V.
The GLC65D provides 65W of total continuous output power.
The input voltage range is 90-264 VAC.
The operating temperature range is 0°C to 50°C.
The minimum efficiency is 80%.
