GEC03SABN-M30 This is a 3-position, single row, surface mount male breakaway header with 2.54mm pitch. It features tin-plated phosphor bronze contacts and a UL94 V-0 rated polyamide insulator.
Mfr Part #:

GEC03SABN-M30

Available from 1 distributors
Mfr Name: Sullins Connector Solutions
Sullins Connector Solutions
This is a 3-position, single row, surface mount male breakaway header with 2.54mm pitch. It features tin-plated phosphor bronze contacts and a UL94 V-0 rated polyamide insulator.
✓ Total Stock: 48 pcs
$ Price Range: $0.41 - $0.79

GEC03SABN-M30 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
48 pcs
On Request
48 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

GEC03SABN-M30 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating (Amps)
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
Shrouding
Style
Termination
Termination Style
View Similar Products (0)

GEC03SABN-M30 Description

Short technical summary and product information.

The GEC03SABN-M30 is a 3-position, single row male breakaway header from Sullins Connector Solutions. It features a 2.54mm pitch and surface mount termination, making it suitable for automated SMD assembly. The unshrouded header has square male pins with tin-plated phosphor bronze contacts, rated for 3A current. The insulator is made of polyamide (PA9T) with a UL94 V-0 flammability rating, ensuring reliable performance in various environments. The operating temperature range is -65°C to 150°C. This connector is designed for board-to-board or cable applications, providing a push-pull fastening type for easy mating and unmating.

GEC03SABN-M30 Quick Information

Product Type: Male Pin Header
Series: GEC
Canonical Name: 3 Position Single Row Surface Mount Male Breakaway Header
Subcategory: Male Pin Header

GEC03SABN-M30 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

GEC03SABN-M30 Estimated Pricing

Qty Low High
1+ $0.79 $0.79
10+ $0.67 $0.67
100+ $0.57 $0.57
500+ $0.51 $0.51
1,000+ $0.49 $0.49
5,000+ $0.43 $0.43
10,000+ $0.41 $0.41

Estimated market price range - modelled values for guidance only, not live distributor offers.

GEC03SABN-M30 Features

  • 3-position single row male header.
  • Surface mount termination for SMD assembly.
  • 2.54mm pitch for standard spacing.
  • Tin-plated phosphor bronze contacts.
  • UL94 V-0 rated insulation material.

GEC03SABN-M30 Applications

  • Board-to-board and cable connections.
  • Used in industrial control systems.
  • Suitable for consumer electronics.
  • Ideal for prototyping and production.

GEC03SABN-M30 FAQs

6 frequently asked questions generated from this part’s specifications.
How many positions does the GEC03SABN-M30 have?

The GEC03SABN-M30 has 3 positions.

What is the pitch of this header?

The pitch is 2.54mm (0.100 inches).

What is the current rating of the GEC03SABN-M30?

The current rating is 3A.

What is the mounting type for this connector?

The mounting type is surface mount (SMD).

What is the operating temperature range?

The operating temperature range is -65°C to 150°C.

What is the contact finish on the pins?

The contact finish is tin with a thickness of 100.0µin (2.54µm).
