Mfr Part #:

GDCX-PN-64-50

Mfr Name: Kycon Inc.

Kycon GDCX-PN-64-50 is a 6p4c (RJ11/RJ14) vertical through hole modular jack with 50µ" gold plating. It is unshielded and rated for 1.5A at 125V DC.

✓ Total Stock: 97 pcs

$ Price Range: $0.71 - $0.79

GDCX-PN-64-50 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Bristol Electronics ✓ Non-Authorised Inventory information	97 pcs On Request	97 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

GDCX-PN-64-50 Description

Short technical summary and product information.

The Kycon GDCX-PN-64-50 is a vertical through hole modular jack from the GDCX-P series. It features a 6-position 4-contact (6p4c) configuration, compatible with RJ11 and RJ14 connections. The jack is unshielded and has a user-selectable tab direction. It is housed in a black PBT thermoplastic housing rated UL 94V-0, with phosphor bronze contacts finished with 50µ" gold plating. Electrical characteristics include a maximum contact resistance of 20 mOhm, minimum insulation resistance of 500 MOhm, and dielectric withstanding voltage of 1000 V RMS. The voltage rating is 125 V DC and current rating is 1.5 A. Operating temperature range is -40°C to +85°C. The connector is designed for through hole solder termination and includes board guide and board lock features for secure mounting. It has a minimum durability of 500 mating cycles. This modular jack is suitable for telecommunications and networking equipment requiring a reliable vertical connection.

GDCX-PN-64-50 Quick Information

Product Type: Modular Connector Jack

Series: GDCX-P Series

Canonical Name: Kycon GDCX-PN-64-50 Modular Jack, 6p4c (RJ11/RJ14), Vertical, Through Hole, Unshielded

Subcategory: RJ11/RJ14 Connector

GDCX-PN-64-50 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

GDCX-PN-64-50 Estimated Pricing

Qty	Low	High
1,100+	$0.79	$0.79
2,530+	$0.74	$0.74
5,060+	$0.71	$0.71

Estimated market price range - modelled values for guidance only, not live distributor offers.

GDCX-PN-64-50 Features

6p4c (RJ11/RJ14) vertical through hole jack.
Rated for 1.5A at 125V DC operation.
50µ" gold plating on phosphor bronze contacts.
Unshielded with user-selectable tab direction.
UL 94V-0 rated PBT thermoplastic housing.

GDCX-PN-64-50 Applications

Used in telecommunications equipment for RJ11 connections.
Ideal for networking devices requiring vertical mounting.
Suitable for through hole PCB assembly in industrial controls.
Applied in telephone and modem interfaces.

GDCX-PN-64-50 FAQs

7 frequently asked questions generated from this part’s specifications.

What is the number of positions and contacts?

6p4c (6 positions, 4 contacts).

What is the mounting type?

Through hole.

What is the current rating?

1.5 A.

What is the voltage rating?

125 V DC.

What is the operating temperature range?

-40°C to +85°C.

What is the durability rating?

500 mating cycles minimum.

Is the connector shielded?

No, it is unshielded.

Category	Modular Connector Jacks
Manufacturer Name	Kycon Inc.
Connector Type	Jack
Contact Finish	Gold
Contact Material	Phosphor Bronze
Contact Resistance	20 mOhm
Current Rating	1.5 A
Dielectric Withstanding Voltage	1000 V RMS
Features	Board Guide, Board Lock
Housing Material	PBT Thermoplastic, UL 94V-0 Rated
Insulation Resistance	500 MOhm
LED Color	Does Not Contain LED
Mounting Type	Through Hole
Number of Ports	1
Number of Positions	6p4c (RJ11, RJ14)
Number of Rows	1
Operating Temperature	-40 to +85 °C
Orientation	Vertical
Shielding	Unshielded
Tab Direction	User Selectable
Tape & Reel	Yes
Termination	Solder
Termination Style	Solder
Voltage Rating	125 V DC
