The Starpower GD30PJX65L2S is an IGBT Power Module offering ultra-low conduction loss and short circuit ruggedness. It is designed for applications such as general inverters and Uninterruptible Power Supplies (UPS).
Key electrical specifications include a 650V Collector-Emitter Voltage (VCES) and a 30A Continuous Collector Current (IC) at 100°C. The module also features a maximum power dissipation of 163W at a junction temperature of 175°C. It utilizes Trench IGBT technology for low VCE(sat) and has a positive temperature coefficient for VCE(sat).
Additional features include a 6μs short circuit capability, fast and soft reverse recovery anti-parallel FWD, and a low inductance case. The module is built with an isolated heatsink using DBC technology. Typical applications include inverters for motor drives, AC and DC servo drive amplifiers, and uninterruptible power supplies.
The operating junction temperature ranges from -40°C to +150°C, with a maximum junction temperature of 175°C for inverter and brake functions, and 150°C for rectifier functions. The isolation voltage RMS is rated at 2500V.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum Collector-Emitter Voltage (VCES) is 650V.
The continuous collector current at 100°C is 30A.
The maximum power dissipation is 163W at Tj=175°C.
The maximum junction temperature for inverter and brake is 175°C, and for rectifier is 150°C.
The typical collector to emitter saturation voltage is 1.45V.
The typical gate-emitter threshold voltage is 5.1V.
The isolation voltage RMS is 2500V.
