| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
933 pcs
|
933 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
910 pcs
|
910 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Automotive Grade | |
| Capacitance | |
| Length | |
| Mounting Type | |
| Operating Temperature | |
| Ratings | |
| SVHC Present | |
| Storage Temperature | |
| Tape & Reel | |
| Temperature Coefficient | |
| Thickness (Max) | |
| Tolerance | |
| Voltage | |
| Width |
The GCQ1555C1H3R3BB01D is a high Q chip multilayer ceramic capacitor (MLCC) from Murata, part of the GCQ series designed for automotive applications. It features a capacitance of 3.3 pF with a tight tolerance of ±0.1 pF and a rated voltage of 50 V DC. The capacitor utilizes a C0G/NP0 dielectric, which offers excellent temperature stability with a ±30 ppm/°C coefficient over the operating range of -55°C to +125°C.
This MLCC is qualified to AEC-Q200, making it suitable for use in automotive electronics such as engine control units, infotainment systems, and RF modules. Its high Q characteristics are ideal for RF and microwave circuits where low loss and high stability are critical. The component is designed for surface mount assembly and is compatible with reflow soldering processes only.
The capacitor is housed in a compact 0402 (1005 metric) package with dimensions of 1.00 mm x 0.50 mm x 0.55 mm (max). It is available in tape and reel packaging with options including 10000, 20000, or 50000 pieces per reel, depending on reel size (180 mm or 330 mm). The component is RoHS3 compliant, REACH unaffected, and has MSL Level 1 unlimited moisture sensitivity.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.20 | $0.20 |
| 10+ | $0.08 | $0.08 |
| 100+ | $0.07 | $0.07 |
| 500+ | $0.05 | $0.05 |
| 1,000+ | $0.05 | $0.05 |
| 2,500+ | $0.04 | $0.04 |
| 5,000+ | $0.04 | $0.04 |
| 10,000+ | $0.04 | $0.04 |
| 20,000+ | $0.03 | $0.03 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
Capacitance is 3.3 pF with a tolerance of ±0.1 pF.
The rated voltage is 50 V DC.
Temperature coefficient is C0G/NP0 with ±30 ppm/°C.
Operating temperature range is -55°C to +125°C.
Package is 0402 (1005 metric) with dimensions 1.00 mm x 0.50 mm x 0.55 mm.
Yes, it is AEC-Q200 qualified.
Available in 330 mm reel (50000 pcs), 180 mm reel paper W8P2 (10000 pcs), or 180 mm reel paper W8P1 (20000 pcs).
