The Lattice Semiconductor GAL22V10D-25QP is a Complex Programmable Logic Device (CPLD) from the GAL22V10 family. It offers 10 macrocells and is designed for high-performance applications, with a maximum propagation delay of 4 ns and a maximum clock frequency of 250 MHz.
This device operates within a supply voltage range of 4.75V to 5.25V and has an operating temperature range of 0°C to 75°C (TA). The GAL22V10D-25QP is packaged in a 24-PDIP (Dual In-line Package) with through-hole mounting. The datasheet indicates that all devices in this series have been discontinued.
Key electrical characteristics include a 3.5 ns maximum delay from clock input to data output. The CPLD utilizes EE PLD technology, allowing for reconfigurable logic. It is compatible with standard 22V10 devices, offering a reduction in power consumption compared to bipolar equivalents.
The maximum propagation delay is 4 ns.
The operating supply voltage is between 4.75V and 5.25V.
The operating temperature range is 0°C to 75°C (TA).
It is supplied in a 24-PDIP (Dual In-line Package) with through-hole mounting.
The device has 10 macrocells.
