| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
84 pcs
|
84 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Current | |
| Coil Type | |
| Coil Voltage | |
| Contact Form | |
| Contact Material | |
| Contact Rating (Current) | |
| Dimensions | |
| Mounting Type | |
| Must Operate Voltage | |
| Must Release Voltage | |
| Operate Time | |
| Operating Temperature | |
| Power Consumption | |
| Relay Type | |
| Release Time | |
| Seal Rating | |
| Switching Voltage | |
| Termination Style |
The Omron G6C-1117P-US-DC5 is a miniature PCB Power Relay designed for high-capacity power switching applications. It features a single pole, single throw normally open (SPST-NO) contact form capable of handling up to 10A.
This relay operates with a 5VDC coil voltage and has a low power consumption of 200 mW. Key electrical specifications include a 3.5 VDC minimum operate voltage and a 0.5 VDC maximum release voltage. The operate and release times are both typically 10 ms. The contact material is Silver Alloy, Cadmium Free, suitable for various power switching needs.
Designed for space-saving, the relay has compact dimensions of 20 x 15 x 10 mm. It is sealed with flux protection, ensuring durability in assembly processes. The mounting type is through hole with PC pin termination, making it suitable for direct PCB mounting.
This general-purpose relay is rated for switching voltages up to 380VAC and 125VDC. It operates within a temperature range of -25°C to 70°C. The G6C series offers models suitable for ultrasonically cleanable applications and exclusive P6C models for sockets.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The coil voltage is 5 VDC.
The contact current rating is 10 A.
The contact form is SPST-NO (1 Form A).
The operating temperature range is -25°C to 70°C.
It is a through hole mounting type with PC pin termination.
The power consumption is 200 mW.
The dimensions are 20 x 15 x 10 mm.
