| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,800 pcs
|
2800 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Features | |
| Height Above Board | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Pitch | |
| Tape & Reel |
The FX22-40S-0.5SH is a 40-position, single-row receptacle connector from Hirose Electric designed for high-density board-to-board and mezzanine applications. It features a 0.50mm pitch and a right-angle surface mount termination, making it suitable for compact, space-constrained designs. The connector includes an integrated board guide for precise alignment during assembly.
The connector has a height above board of 4.20mm, allowing for low-profile stacking configurations. It is RoHS3 compliant, REACH unaffected, and has a Moisture Sensitivity Level (MSL) of 1 (unlimited floor life), enabling flexible handling and storage.
Typical applications include portable electronics, computing devices, and any system requiring high-density interconnect with a reliable right-angle connection. The single-row design with 40 positions supports parallel board stacking with a 0.5mm pitch for signal routing.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.70 | $2.70 |
| 10+ | $2.30 | $2.30 |
| 25+ | $2.05 | $2.05 |
| 100+ | $1.95 | $1.95 |
| 250+ | $1.91 | $1.91 |
| 700+ | $1.83 | $1.83 |
| 1,400+ | $1.78 | $1.78 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
40 positions.
0.50mm (0.020").
Surface Mount, Right Angle.
4.20mm (0.165").
Yes, it includes a board guide feature.
RoHS3 Compliant (unverified).
MSL 1 (Unlimited).
