| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Dimensions | |
| Efficiency | |
| Failure Rate | |
| Form | |
| Height | |
| Input Connector | |
| Input Type | |
| Input Voltage | |
| Length | |
| Operating Temperature | |
| Output Connector | |
| Output Current | |
| Output Voltage | |
| Polarization | |
| Power | |
| Power (Watts) | |
| Region Utilized | |
| Voltage | |
| Weight | |
| Width |
This AC/DC desktop adapter from ICCNexergy (Inventus Power), part number FW5012-760-NC, delivers 50W of power with a stable 12V output and a maximum current of 4.15A. It is designed for international use, accepting an input voltage range of 100 to 240 VAC.
The adapter features an IEC 320-C14 input connector and a standard Barrel Plug output connector (2.5mm I.D. x 5.5mm O.D. x 9.5mm) with positive center polarization. Its dimensions are 127.0mm x 76.2mm x 33.0mm, making it suitable for desktop applications classified as Class I.
With an efficiency rating of 80%, this adapter operates within a temperature range of 0°C to 60°C. It is intended for ITE (Commercial) applications and requires a separate power cord.
Note that the RoHS status is listed as Non-Compliant, and the Moisture Sensitivity Level (MSL) is 1.
The FW5012-760-NC adapter has an output voltage of 12V and a maximum output current of 4.15A.
The adapter accepts an input voltage range of 100 to 240 VAC.
The adapter uses an IEC 320-C14 input connector.
The dimensions of the adapter are 127.0mm x 76.2mm x 33.0mm.
The adapter operates within a temperature range of 0°C to 60°C.
