| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Form | |
| Frequency | |
| Height | |
| Input Connector | |
| Input Type | |
| Length | |
| Operating Temperature | |
| Output Connector | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| Storage Temperature | |
| Voltage | |
| Width |
This Inventus Power FW1805-760-NC is an 18 Watt AC/DC desktop adapter designed for ITE (Commercial) applications. It provides a regulated 5V output at 3A, delivering up to 15W of power.
The adapter features a wide range AC input (100-240 VAC) and operates with 80% nominal efficiency at full load and 115 VAC. It includes built-in over-voltage and over-current protection, with short circuit protection in pulsing mode and auto-recovery.
The unit utilizes a standard IEC 320-C14 input connector and a barrel type output connector (5.5 x 2.5 x 9.5 mm) with a positive center polarity. Its dimensions are 85.0mm x 50.0mm x 33.0mm.
Environmental specifications include an operating temperature range of 0°C to 60°C and a storage temperature range of -55°C to 85°C. It meets FCC class B and CISPR 22 class B EMI standards.
100-240 VAC, 47-63 Hz.
5V at 3A (15W).
Barrel plug with 2.5mm ID, 5.5mm OD, 9.5mm length, positive center.
Yes, pulsing mode with auto recovery.
0°C to 60°C.
80% at full load and 115 VAC.
