FW-05-03-L-D-156-156 The Samtec FW-05-03-L-D-156-156 is a 1.27mm pitch board stacker with 10 positions and 2 rows. It features surface mount termination and a 0.156 inch stack height.
Mfr Part #:

FW-05-03-L-D-156-156

Available from 1 distributors
Mfr Name: SMT
SMT
The Samtec FW-05-03-L-D-156-156 is a 1.27mm pitch board stacker with 10 positions and 2 rows. It features surface mount termination and a 0.156 inch stack height.
✓ Total Stock: 2,600 pcs
$ Price Range: $0.77

FW-05-03-L-D-156-156 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Husky International Electronic ✓
Non-Authorised Inventory information
2,600 pcs
On Request
2600 pcs On Request 1 On Request On Request N/A On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

FW-05-03-L-D-156-156 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Contact Plating
Halogen Free
Height
Lead Style
Mounting Type
Number of Positions
Number of Rows
Pitch
Tape & Reel
View Similar Products (0)

FW-05-03-L-D-156-156 Description

Short technical summary and product information.

The Samtec FW-SM series board stacker, part number FW-05-03-L-D-156-156, is a surface-mount PCB header system designed for flexible board stacking heights. This connector has 10 positions arranged in 2 rows with a 1.27mm (0.050 inch) pitch.



Key specifications include a stack height of 0.156 inches and a post height of 0.156 inches. The contacts are plated with 10 microinches of Gold/Tin. The system is rated for 8 Gbps NRZ Channel Performance Metric (CPM).



Features such as end shroud, guide post, and optional tape and reel packaging are available. The manufacturing process allows for precise adjustment of the body on the terminal pin in increments of 0.005 inches (0.13 mm), enabling custom stack heights. This connector is suitable for applications requiring reliable board-to-board connections with specific height requirements.

FW-05-03-L-D-156-156 Quick Information

Product Type: Board Stacker
Series: FW-SM
Canonical Name: Samtec FW-SM Series Board Stacker
Subcategory: Board Stacker

FW-05-03-L-D-156-156 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

FW-05-03-L-D-156-156 Estimated Pricing

Qty Low High
1+ $0.77 $0.77

Estimated market price range - modelled values for guidance only, not live distributor offers.

FW-05-03-L-D-156-156 Features

  • 1.27mm pitch, 10 position board stacker.
  • Surface mount termination (SMT).
  • 0.156 inch stack height.
  • 10 microinch Gold/Tin contact plating.
  • 8 Gbps NRZ CPM rating.

FW-05-03-L-D-156-156 Applications

  • Board-to-board stacking for compact designs.
  • High-speed data transmission up to 8 Gbps.
  • Surface mount assembly for automated production.
  • Flexible stack height for non-standard spacing.
  • Suitable for SATA and SAS interfaces.

FW-05-03-L-D-156-156 FAQs

6 frequently asked questions generated from this part’s specifications.
What is the pitch of the Samtec FW-05-03-L-D-156-156 board stacker?

The pitch of this board stacker is 1.27 mm.

How many positions does the FW-05-03-L-D-156-156 connector have?

This connector has 10 positions.

What is the stack height for this Samtec board stacker?

The stack height is 0.156 inches.

What type of mounting does the FW-05-03-L-D-156-156 use?

It uses Surface Mount (SMT) mounting.

What is the contact plating on the FW-05-03-L-D-156-156?

The contact plating is 10 microinches Gold/Tin.

What is the Channel Performance Metric (CPM) for this connector?

The CPM is 8 Gbps NRZ.
