Mfr Part #:

FTSH-150-01-L-DV

Available from 1 distributors

Mfr Name: Samtec Inc.

Connector Header, Male Pin, 100 positions, 2 rows, 1.27mm pitch, surface mount, unshrouded. Tin contact finish.

✓ Total Stock: 1,000 pcs

$ Price Range: $4.74 - $13.70

FTSH-150-01-L-DV Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Braun Electronic Components ✓ Non-Authorised Inventory information	1,000 pcs On Request	1000 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

FTSH-150-01-L-DV Description

Short technical summary and product information.

The Samtec FTSH-150-01-L-DV is a high-density header connector part of the FTSH series. It features 100 male pin contacts arranged in 2 rows at a 1.27mm pitch, making it suitable for compact board-to-board or cable applications. The connector is unshrouded with a push-pull fastening type and is surface mountable for efficient PCB assembly. Contacts are made of phosphor bronze with a tin finish (10µin thickness) and rated for 3.4A per contact when 2 pins are powered. The insulator is black liquid crystal polymer (LCP) with a flammability rating of UL94 V-0, ensuring reliable performance in a wide temperature range of -55°C to +125°C. The header is designed for cuttable applications, allowing customization of position count. Lead-free solderable and compatible with tape and reel packaging (option -TR). This connector is ideal for applications requiring high pin count in a small footprint.

FTSH-150-01-L-DV Quick Information

Product Type: Header, Male Pin

Series: FTSH

Canonical Name: FTSH-150-01-L-DV 100 Position Header, Male Pin, SMD, 1.27mm Pitch

Subcategory: Rectangular Connectors

FTSH-150-01-L-DV Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

FTSH-150-01-L-DV Estimated Pricing

Qty	Low	High
1+	$13.70	$13.70
9+	$7.83	$7.83
27+	$7.57	$7.57
54+	$7.24	$7.24
108+	$6.99	$6.99
252+	$6.24	$6.24
504+	$5.52	$5.52
1,008+	$5.12	$5.12
2,502+	$4.74	$4.74

Estimated market price range - modelled values for guidance only, not live distributor offers.

FTSH-150-01-L-DV Features

100 positions in 2 rows with 1.27mm pitch.
Surface mount design for compact PCB assembly.
Tin plated phosphor bronze contacts rated 3.4A.
Black LCP insulator with UL94 V-0 rating.
Operating temperature range -55°C to +125°C.

FTSH-150-01-L-DV Applications

High-density board-to-board connections.
Compact electronic devices requiring many I/O lines.
Suitable for cuttable applications to customize length.

FTSH-150-01-L-DV FAQs

5 frequently asked questions generated from this part’s specifications.

What is the number of positions?

100 positions in 2 rows.

What is the pitch?

1.27mm (0.050") pitch.

What is the current rating?

3.4A per contact (2 pins powered).

What is the mounting type?

Surface mount (SMD) with solder termination.

What is the operating temperature range?

-55°C to +125°C.

Category	Headers, Male Pins
Manufacturer Name	Samtec Inc.
AEC Qualified	No
Automotive Grade	No
Connector Type	Header, Cuttable
Contact Finish	Tin
Contact Finish Thickness	10.0µin (0.25µm)
Contact Length	3.05mm (0.120")
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	3.4A per Contact
Fastening Type	Push-Pull
Industrial Grade	No
Insulation Color	Black
Insulation Height	2.51mm (0.099")
Insulation Material	Liquid Crystal Polymer (LCP)
Lead Spacing	1.27 mm
Lead Style	Smd
Material Flammability Rating	UL94 V-0
Medical Grade	No
Military Grade	No
Mounting Type	Surface Mount
Number of Positions	100
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature	-55°C ~ 125°C
Pitch	1.27mm (0.050")
Row Spacing	0.050" (1.27mm)
SVHC Present	Not Present
Shrouding	Unshrouded
Style	Board to Board or Cable
Tape & Reel	No
Termination	Solder
