FTSH-108-01-F-D-RA-K This is a 16 position, 2 row, 1.27mm pitch shrouded male pin header from Samtec. It features a right angle through hole mounting with tin plated phosphor bronze contacts.
Mfr Part #:

FTSH-108-01-F-D-RA-K

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
This is a 16 position, 2 row, 1.27mm pitch shrouded male pin header from Samtec. It features a right angle through hole mounting with tin plated phosphor bronze contacts.
✓ Total Stock: 116 pcs
$ Price Range: $1.71 - $3.22

FTSH-108-01-F-D-RA-K Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Speed Components Ltd ✓
Non-Authorised Inventory information
116 pcs
On Request
116 pcs On Request 1 On Request On Request 11+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

FTSH-108-01-F-D-RA-K Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating (Amps)
Fastening Type
Features
Insulation Color
Insulation Height
Insulation Material
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
Row Spacing
Shrouding
Style
Tape & Reel
Termination
Termination Style
View Similar Products (0)

FTSH-108-01-F-D-RA-K Description

Short technical summary and product information.

The Samtec FTSH-108-01-F-D-RA-K is a 16-position, 2-row, 1.27mm pitch shrouded header designed for board-to-board or cable connections. It features male pins and a right angle through hole mounting style with a push-pull fastening system and a keying shroud for alignment.



Each contact is rated for 3.4A and constructed from phosphor bronze with a tin finish. The header uses Liquid Crystal Polymer (LCP) insulation with a UL94 V-0 flammability rating and operates over a temperature range of -55°C to 125°C.



Environmental compliance includes RoHS3, REACH, and MSL 1 ratings (unverified). The component is available in a standard through hole package for solder termination.

FTSH-108-01-F-D-RA-K Quick Information

Product Type: Header, Male Pins
Series: FTSH
Canonical Name: 16 Position 1.27mm Pitch Through Hole Right Angle Shrouded Header, Male Pins
Subcategory: Headers, Male Pins

FTSH-108-01-F-D-RA-K Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

FTSH-108-01-F-D-RA-K Estimated Pricing

Qty Low High
1+ $3.22 $3.22
57+ $2.75 $2.75
114+ $2.36 $2.36
513+ $2.18 $2.18
1,026+ $2.02 $2.02
2,052+ $1.86 $1.86
5,016+ $1.71 $1.71

Estimated market price range - modelled values for guidance only, not live distributor offers.

FTSH-108-01-F-D-RA-K Features

  • 16 position, 2 row, 1.27mm pitch.
  • Right angle through hole mounting.
  • Shrouded header with keying shroud.
  • Tin plated phosphor bronze contacts.
  • Rated for 3.4A per contact.

FTSH-108-01-F-D-RA-K Applications

  • Ideal for board-to-board interconnects.
  • Used in cable to header assemblies.
  • Suitable for compact electronic devices.

FTSH-108-01-F-D-RA-K FAQs

7 frequently asked questions generated from this part’s specifications.
What is the number of positions?

This header has 16 positions.

What is the pitch of this header?

The pitch is 1.27mm (0.050").

What is the current rating?

It is rated for 3.4A per contact.

What is the mounting type?

It is a through hole, right angle mounting.

What is the contact material?

The contact material is phosphor bronze.

What is the insulation material?

The insulation material is Liquid Crystal Polymer (LCP).

What is the operating temperature range?

The operating temperature range is -55°C to 125°C.
