| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,186 pcs
|
1186 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Halogen Free | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Prop 65 | |
| Row Spacing | |
| SVHC Present | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination |
The Samtec FTS-125-01-F-DV is a micro low profile header strip from the FTS series, designed for board-to-board or cable applications. It features 50 positions arranged in 2 rows on a 1.27mm pitch, with a 1.27mm row spacing. The connector uses square phosphor bronze male pins with a gold flash on the post and matte tin on the tail, providing reliable electrical contact.
This header is surface mount (SMT) with a solder termination, and the insulation is black liquid crystal polymer (LCP) rated UL94 V-0. The unshrouded push-pull design allows for easy mating and unmating. The contact length (post height) is 3.05mm, and the insulation height is 0.86mm.
Electrical rating is 3.4A per contact (2 pins powered), and the operating temperature range spans -55°C to 125°C. The SMT lead coplanarity is a maximum of 0.10mm. The part is packaged in tubes with 18 pieces per tube.
Compliance includes RoHS3, REACH (no SVHCs), lead-free solderable, halogen free (Br/Cl per JS-709C), and MSL Level 1. California Proposition 65 warning applies for nickel exposure.
| Qty | Low | High |
|---|---|---|
| 1+ | $4.68 | $4.68 |
| 18+ | $4.48 | $4.48 |
| 54+ | $4.17 | $4.17 |
| 108+ | $3.85 | $3.85 |
| 504+ | $3.38 | $3.38 |
| 1,008+ | $2.84 | $2.84 |
| 2,502+ | $2.36 | $2.36 |
| 5,004+ | $2.33 | $2.33 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
50 positions arranged in 2 rows.
1.27mm (0.050") pitch with 1.27mm row spacing.
3.4A per contact (2 pins powered).
-55°C to 125°C.
Surface mount (SMT) with solder termination.
Gold flash on post, matte tin on tail.
Yes, RoHS3 compliant (unverified).
