| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4,375 pcs
|
4375 pcs | On Request | 1 | On Request | On Request | 21+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style |
The Samtec FTS-103-04-F-DV-TR is a 6-position, 2-row unshrouded header from the FTS series of micro low profile terminal strips. It features a 1.27mm pitch and 1.27mm row spacing, making it suitable for high-density board-to-board or cable applications. The connector uses surface mount termination with solder tails and is supplied in tape and reel packaging.
The header has square male pins with a contact length of 3.81mm. The contact finish is gold flash on the post and matte tin on the tail, over a 50 microinch nickel underplate. The insulator is black liquid crystal polymer (LCP) with a UL94 V-0 flammability rating. The part is lead-free solderable and has a maximum SMT lead coplanarity of 0.10mm.
Electrical rating is 3.4A per contact (with 2 pins powered). The operating temperature range is -55°C to 125°C. The push-pull fastening type and unshrouded design allow for easy mating and unmating. This connector mates with Samtec CLP and FLE series board-mount receptacles, and FFSD series cable assemblies.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.44 | $1.44 |
| 50+ | $1.33 | $1.33 |
| 100+ | $1.09 | $1.09 |
| 625+ | $0.96 | $0.96 |
| 1,250+ | $0.94 | $0.94 |
| 1,875+ | $0.88 | $0.88 |
| 5,000+ | $0.79 | $0.79 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 1.27mm (0.050").
It has 6 positions arranged in 2 rows, with 3 positions per row.
The current rating is 3.4A per contact (with 2 pins powered).
Surface mount (SMD) with solder termination.
-55°C to 125°C.
Yes, the datasheet confirms it is lead-free solderable.
