FTMH-111-02-F-DV-ES-A-P-TR This is a 22 position, 2 row, 1.00mm pitch surface mount unshrouded header from Samtec's FTMH series. It features male pins with tin contact finish and a black LCP insulator.
Mfr Part #:

FTMH-111-02-F-DV-ES-A-P-TR

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
This is a 22 position, 2 row, 1.00mm pitch surface mount unshrouded header from Samtec's FTMH series. It features male pins with tin contact finish and a black LCP insulator.
✓ Total Stock: 88 pcs
$ Price Range: $3.65 - $3.82

FTMH-111-02-F-DV-ES-A-P-TR Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Speed Components Ltd ✓
Non-Authorised Inventory information
88 pcs
On Request
88 pcs On Request 1 On Request On Request 1830 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

FTMH-111-02-F-DV-ES-A-P-TR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating (Amps)
Fastening Type
Features
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
Row Spacing
Shrouding
Style
Tape & Reel
Termination
View Similar Products (0)

FTMH-111-02-F-DV-ES-A-P-TR Description

Short technical summary and product information.

The Samtec FTMH-111-02-F-DV-ES-A-P-TR is a 22-position, 2-row, 1.00mm pitch surface mount unshrouded header designed for board-to-board applications. It features male pins made of phosphor bronze with a tin contact finish and a black liquid crystal polymer (LCP) insulator. The connector includes features such as a board guide, end shrouds, and a plastic pick and place pad for automated assembly.



This header is rated for a current of 2.8A per contact and has an operating temperature range of -55°C to +125°C. The insulation material has a UL94 V-0 flammability rating. The connector is packaged on tape and reel and is lead-free solderable.



The part number FTMH-111-02-F-DV-ES-A-P-TR indicates a dual vertical orientation with an end shroud and alignment pin option. The -TR suffix denotes tape and reel packaging. This connector is suitable for use in various electronic systems requiring a compact, high-density interconnect solution.

FTMH-111-02-F-DV-ES-A-P-TR Quick Information

Product Type: Header, Male Pins
Series: FTMH
Canonical Name: Samtec FTMH Series 22 Position 2 Row 1mm Pitch Surface Mount Unshrouded Header, Male Pins
Subcategory: Header, Unshrouded

FTMH-111-02-F-DV-ES-A-P-TR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Lead-Free Solderable: Yes

FTMH-111-02-F-DV-ES-A-P-TR Estimated Pricing

Qty Low High
750+ $3.82 $3.82
2,250+ $3.65 $3.65

Estimated market price range - modelled values for guidance only, not live distributor offers.

FTMH-111-02-F-DV-ES-A-P-TR Features

  • 22 positions in 2 rows with 1.00mm pitch.
  • Surface mount unshrouded header for SMT assembly.
  • Rated for 2.8A per contact current.
  • Operating temperature range from -55°C to +125°C.
  • Includes board guide, end shrouds, and pick and place pad.

FTMH-111-02-F-DV-ES-A-P-TR Applications

  • Ideal for compact board-to-board interconnections.
  • Suitable for high-density electronic assemblies.
  • Used in automated pick and place manufacturing processes.

FTMH-111-02-F-DV-ES-A-P-TR FAQs

7 frequently asked questions generated from this part’s specifications.
What is the pitch of this connector?

The pitch is 1.00mm.

How many positions does this header have?

This header has 22 positions.

What is the mounting type for this part?

The mounting type is surface mount.

What is the current rating per contact?

The current rating is 2.8A per contact.

What is the operating temperature range?

The operating temperature range is -55°C to +125°C.

What is the contact finish?

The contact finish is tin.

Is this connector RoHS compliant?

RoHS compliance is unverified but the part is lead-free solderable.
