| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Frequency | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Relative Humidity | |
| Standard Number | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
The FSP250-H24-A12 is an AC-DC switching power supply designed for information and networking applications. It features a compact 2"x4"x1.283" open frame form factor suitable for chassis mounting.
This power supply offers a 12V output and can deliver 250 watts of continuous power with 14 CFM forced air cooling, or 150 watts with convection cooling at a 50℃ operation temperature. It operates within a wide input voltage range of 90-264 VAC and features a power factor of 0.98 minimum at 115VAC.
Key electrical specifications include over-voltage, short-circuit, over-current, and over-temperature protections. It meets IEC 62368-1 safety standards and exhibits EN 55032 Class B radiated emission performance. The operating temperature range is -20℃ to +70℃.
Designed for ITE (Commercial) applications, this power supply is built with Class-I design principles and includes features like PFC and universal input. Its dimensions are 101.6mm x 50.8mm x 32.5mm.
90-264 VAC.
-20°C to +70°C.
Open frame, chassis mount.
12V at 20.83A.
250W with forced air cooling, 150W with convection cooling.
Over voltage (latch off), short circuit (auto recovery), overcurrent (auto recovery), over temperature (latch off).
IEC 62368-1, CE, cURus.
