| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Frequency | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Protection | |
| Standard Number | |
| Storage Temperature | |
| Type | |
| Voltage | |
| Width |
The FSP250-50TAC is an ATX form factor AC/DC converter designed for ITE (Commercial) applications. It provides a total power output of 353W and features 80 Plus Bronze efficiency, indicating up to 85% efficiency.
This converter operates with a universal input voltage range of 90-264Vac and a frequency of 50-60Hz. It includes multiple outputs: +3.3V, +5V, +12V, -12V, and +5Vsb, with specific current ratings for each. The unit is built with complete protection features including Over Current Protection, Over Temperature Protection, and Over Voltage Protection to ensure system stability and reliability.
With dimensions of 175 x 85 x 65 mm, the FSP250-50TAC is designed for chassis mounting. It meets safety standards such as CB 62368-1, CE, cURus, FCC, and TUV, making it suitable for various system builds requiring a stable power supply unit.
The input voltage range is 90-264Vac at 50-60Hz.
Dimensions are 175.0mm x 85.1mm x 65.0mm with chassis mount ATX form factor.
The operating temperature range is 0°C to 50°C.
The total output power is 353W.
+3.3V: 12A, +5V: 12A, +12V: 20.83A, -12V: 0.3A, +5Vsb: 2.5A. Combined +3.3V and +5V total not to exceed 65W.
Over voltage protection, over current protection, and over temperature protection are included.
It has an 80 Plus Bronze efficiency rating.
