| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| SVHC Present | |
| Storage Temperature | |
| Type | |
| Voltage | |
| Width |
The FSP-FC250 is a Power Distribution Board (PDB) designed for CRPS (Common Redundant Power Supply) systems. It supports a total power output of up to 2400 Watts and features a short length and PMBus capability, making it suitable for datacenter, workstation, and telecom applications.
Key electrical specifications include a universal input voltage range of 100-240 VAC. The PDB provides multiple DC outputs: +3.3V (up to 12A), +5V (up to 24A), +12V (up to 196.7A), -12V (up to 0.3A), and +5VSB (up to 5A). The maximum combined power for +3.3V is 972W, for +5V is 3.6W, and for +5VSB is 25W.
Environmental specifications include an operating temperature range of 0°C to 55°C and a storage temperature range of -20°C to +80°C. It operates within a humidity range of 5% to 90% RH (non-condensing) and can function at altitudes up to 5,000 meters above sea level. The MTBF is rated at 500,000 hours.
Mechanically, the FSP-FC250 has dimensions of 210.1mm x 76.2mm x 83.8mm (8.27" x 3.00" x 3.30"). It features a 2U narrow form factor and is designed for rack mounting. Additional features include modular cable management, PMBus 1.2 compliance, high reliability, low ripple and noise, and protections for over current, over temperature, and over voltage.
100-240 VAC.
Rack mount, 2U narrow form factor, dimensions 210.1 x 76.2 x 83.8 mm.
0°C to 55°C operating, -20°C to 80°C storage.
2524W.
Over current, over temperature, and over voltage protection.
Yes, it supports PMBus 1.2.
500,000 hours at 55°C and 100% load.
