| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The FSP-FC210 is a high-reliability Power Distribution Board (PDB) designed to be compatible with CRPS (Common Redundant Power Supply) standards. It features a 2U narrow form factor and supports a total power output of up to 2400 Watts. The PDB is equipped with PMBus capability, making it a suitable choice for demanding applications such as datacenters, workstations, and telecom systems.
Key technical specifications include dimensions of 210 x 76 x 83.8 mm, an operating temperature range of 0°C to 55°C, and a Mean Time Between Failures (MTBF) of 500,000 hours at 55°C and 100% load. The device offers multiple DC outputs including +3.3V, +5V, +12V, -12V, and +5VSB, with specific current and combined power ratings detailed in the datasheet. It also includes protections for Over Current, Over Temperature, and Over Voltage.
Designed for reliability and performance, the FSP-FC210 operates at altitudes up to 5,000 meters above sea level. Its robust construction and features like low ripple and noise contribute to its suitability for industrial and commercial ITE applications. The board is compatible with CRPS modules and meets PMBus 1.2 standards.
0°C to 55°C.
Rack mount with dimensions 210.1mm x 76.2mm x 83.8mm.
2524W.
4 outputs: 3.3V, 5V, +/-12V.
500,000 hours at 55°C, 100% load per SR-332 Issue 2.
11ms at 12V, 70ms at 12Vsb.
Up to 5,000 meters above sea level.
