The FSC-S30-24U is a 30W AC/DC converter from CUI Inc. that delivers a regulated 24V output at 1.25A. It accepts a wide input voltage range of 85-264 VAC (47-440 Hz) or 110-340 VDC, making it suitable for global applications. The converter achieves 86% typical efficiency and features tight line and load regulation of ±1%.
Protection features include automatic recovery over-current protection and over-temperature protection at 145°C. The unit provides 3000 VAC isolation between primary and secondary. Output ripple and noise is limited to 200 mVp-p, and voltage tolerance is ±3%.
The converter operates over a -10°C to 60°C temperature range. It has a rise time of 400 ms and a hold-up time of 10 ms. This model is designed for general-purpose AC/DC conversion in industrial and commercial equipment.
The output voltage is 24 V and the maximum output current is 1.25 A.
The AC input range is 85-264 VAC and the DC input range is 110-340 VDC.
The operating temperature range is -10°C to 60°C.
It has automatic recovery over-current protection and over-temperature protection at 145°C.
The typical efficiency is 86%.
