| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
815 pcs
|
815 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Configuration | |
| Current | |
| Height (Max) | |
| Lens Color | |
| Lens Size | |
| Lens Style | |
| Lens Transparency | |
| Millicandela Rating | |
| Mounting Type | |
| Operating Temperature | |
| Outer Dimension | |
| Power Dissipation | |
| Storage Temperature | |
| Supplier Device Package | |
| Viewing Angle | |
| Voltage | |
| Wavelength |
The Stanley Electric FR1105W-TR is a red, single-color dome lens type LED. It features a dominant wavelength of 626nm and a typical luminous intensity of 180mcd. The LED has a viewing angle of 50 degrees and operates with a forward current of 20mA and a forward voltage of 1.9V.
This component is a surface mount type, housed in a 1206 (3216 metric) package. Its dimensions are 3.2mm in length, 1.6mm in width, and a maximum height of 2.05mm. The lens color is colorless, and the lens style is round with a domed top.
Designed for high reliability applications, this LED is suitable for use in automotive indicators, meter panels, and car audio/heater controls. It is lead-free soldering compatible and RoHS compliant. The operating temperature range is -40°C to 100°C, with storage temperatures ranging from -40°C to 110°C for InGaN and -40°C to 120°C for AlGaInP.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.08 | $0.08 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The dominant wavelength is 626 nm.
The typical luminous intensity is 180 mcd.
The viewing angle is 50 degrees.
The outer dimensions are 3.2 mm x 1.6 mm x 1.85 mm.
The operating temperature range is -40°C to 100°C.
It is supplied in a 1206 (3216 metric) package.
