FOD8802DR2 The On Semiconductor FOD8802DR2 is a dual channel optoisolator featuring transistor output and 2500Vrms isolation. It is supplied in an 8-SOIC package.
Mfr Part #:

FOD8802DR2

Available from 1 distributors
Mfr Name: On Semiconductor
On Semiconductor
The On Semiconductor FOD8802DR2 is a dual channel optoisolator featuring transistor output and 2500Vrms isolation. It is supplied in an 8-SOIC package.
✓ Total Stock: 10,000 pcs
$ Price Range: $0.99

FOD8802DR2 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Flip Electronics ✓
Non-Authorised Inventory information
10,000 pcs
On Request
10000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

FOD8802DR2 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Input Type
Lead Style
Number of Channels
Output Type
Tape & Reel
View Similar Products (0)

FOD8802DR2 Description

Short technical summary and product information.

The FOD8802DR2 from onsemi is a dual-channel optoisolator designed for reliable signal isolation in electronic circuits. It provides a high isolation voltage of 2500Vrms, ensuring safety and performance in demanding applications.



This optoisolator features a transistor output type and operates with a DC input. Key electrical characteristics include a minimum current transfer ratio (CTR) of 70% at 1mA and a maximum CTR of 380% at 1mA. The typical turn-on and turn-off times are both 6µs, with rise and fall times of 6µs and 7µs respectively. The maximum output voltage is 75V, and the output current per channel is 30mA.



Packaged in an 8-SOIC format, the FOD8802DR2 is suitable for surface-mount designs. Its robust specifications make it a versatile component for applications requiring electrical isolation between circuits, such as power supply control, motor drives, and industrial automation.

FOD8802DR2 Quick Information

Product Type: Optoisolator
Series: OptoHit
Canonical Name: FOD8802DR2 Dual Channel Optoisolator
Subcategory: Transistor, Photovoltaic Output Optoisolators

FOD8802DR2 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

FOD8802DR2 Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

FOD8802DR2 Features

  • Dual channel optoisolator with transistor output.
  • High isolation voltage of 2500Vrms.
  • Current transfer ratio from 70% to 380%.
  • Fast typical switching times of 6µs.
  • Compact 8-SOIC package for surface mounting.

FOD8802DR2 Applications

  • Ideal for power supply control circuits.
  • Used in motor drive applications.
  • Suitable for industrial automation systems.
  • Provides signal isolation in communication interfaces.

FOD8802DR2 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the isolation voltage of the FOD8802DR2?

The isolation voltage is 2500Vrms.

What is the current transfer ratio (CTR) for the FOD8802DR2?

The current transfer ratio is a minimum of 70% and a maximum of 380% at 1mA.

What are the typical turn-on and turn-off times?

The typical turn-on and turn-off times are both 6µs.

What is the maximum output voltage and current per channel?

The maximum output voltage is 75V and the output current per channel is 30mA.

What package type is the FOD8802DR2 supplied in?

The FOD8802DR2 is supplied in an 8-SOIC package.
