| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,095 pcs
|
1095 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
850 pcs
|
850 pcs | On Request | 1 | On Request | On Request | 1129 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Current | |
| Mounting Type | |
| Number of Channels | |
| Operating Temperature | |
| Output Type | |
| Static dV | |
| Supplier Device Package | |
| Turn On Time | |
| Voltage | |
| Zero Crossing Circuit |
The ON Semiconductor FOD4118 is a 6-pin DIP optocoupler designed for driving discrete triacs. It features a high blocking voltage of 800V and a peak on-state current of 300mA. The device offers zero-voltage crossing and high static dv/dt of 10 kV/µs.
This optocoupler is suitable for applications such as solid-state relays, industrial controls, lighting controls, static power switches, and AC motor starters. It meets safety and regulatory approvals including UL1577 and DIN-EN/IEC60747-5-5.
The FOD4118 is mounted via through-hole and operates within a temperature range of -55°C to 100°C. It provides isolation with a test voltage of 5000Vrms.
Key electrical characteristics include a typical trigger sensitivity of 2mA and a turn-on time of 60µs. The device is Pb-free and RoHS compliant.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The FOD4118 has a blocking voltage of 800 V.
The FOD4118 has a peak on-state current of 300 mA.
Yes, the FOD4118 features a zero crossing circuit.
The operating temperature range for the FOD4118 is -55°C to 100°C.
The FOD4118 is available in a 6-DIP package.
