| Category | |
| Manufacturer Name | |
| Applications | |
| Country of Origin | |
| Current | |
| Depth | |
| Efficiency | |
| Features | |
| Height | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Power (Watts) | |
| Power Rating | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The Bel Power Solutions FNP600-48G is a high-performance front-end AC/DC switch mode power supply (SMPS) designed for demanding applications. It delivers a stable 48V DC output at up to 12.6A, with a total power rating of 600W. This unit operates efficiently with an efficiency of 89.5% and accepts a wide input voltage range of 90 to 264V ac.
Key features include an I²C interface, load sharing capabilities, power factor correction (PFC), and remote sense functionality, making it suitable for ITE (Commercial) applications. The FNP600-48G is built for reliability, operating within a temperature range of 0°C to +50°C. Its mechanical specifications include dimensions of 298.2mm in length, 40.6mm in width, and 83.8mm in depth, with a weight of 1kg. The mounting type is rack mount.
Compliance information indicates RoHS3 compliance, Moisture Sensitivity Level 1, and REACH unaffected status, though these are noted with low confidence due to lack of verification.
The input voltage range is 90-264V AC.
The output voltage is 48V DC and the output current is 12.6A.
The power rating is 600W.
The efficiency is 89.5%.
The operating temperature range is 0°C to +50°C.
The mounting type is Rack Mount.
Yes, it includes Power Factor Correction (PFC).
