| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
60 pcs
|
60 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Configuration | |
| Current | |
| Filter Type | |
| Flammability Rating | |
| Frequency | |
| High Potential Test Voltage (Minimum @ P->N, 2 sec) | |
| High Potential Test Voltage (Minimum @ P->PE, 2 sec) | |
| Inductance | |
| MTBF | |
| Maximum Continuous Voltage | |
| Maximum Operating Altitude | |
| Mounting Type | |
| Nominal Operating Voltage | |
| Operating Temperature | |
| Overvoltage Category | |
| Pollution Degree | |
| Termination Style | |
| Voltage |
The Schaffner FN2090-10-06 is a single-phase two-stage EMC/RFI filter designed for high attenuation of differential and common-mode noise. It operates from DC to 400Hz and is rated for a maximum continuous voltage of 250VAC/VDC with a nominal operating voltage of 230VAC. The filter is rated for 10A current at 40°C. It features a chassis mount design with quick connect terminals for easy installation. The filter is suitable for applications requiring compliance with EMC standards. It has approvals including CE, CSA, ENEC, and UR. The operating temperature range is -25°C to +100°C. The filter includes high potential test ratings of 1100VDC (P->N) and 2000VAC (P->PE). MTBF is >1,300,000 hours at 40°C/230V. The filter is RoHS3 compliant and has UL 94 V-0 flammability rating for the terminal plastic.
| Qty | Low | High |
|---|---|---|
| 1+ | $56.86 | $56.86 |
| 10+ | $50.90 | $50.90 |
| 20+ | $42.22 | $42.22 |
| 60+ | $41.35 | $41.35 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum continuous operating voltage is 250 VAC/VDC, with a nominal operating voltage of 230 VAC. It also supports 110V.
-25°C to +100°C.
Yes, it is RoHS3 compliant (unverified).
10 A.
Chassis mount with quick connect terminals.
CE, CSA, ENEC, UR.
Greater than 1,300,000 hours at 40°C/230 V.
