| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
7 pcs
|
7 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Configuration | |
| Current | |
| Filter Type | |
| Frequency | |
| Inductance | |
| Medical Grade | |
| Mounting Type | |
| Operating Temperature | |
| SVHC Present | |
| Termination Style | |
| Voltage |
The Schaffner FN2010B-16-06 is a single-phase EMC/RFI filter from the FN2010 series, designed for general purpose AC/DC applications. It is rated for a continuous operating voltage of 250 VAC/DC and a rated current of 16 A at 40°C. The filter operates over a frequency range from DC to 400 Hz and provides single-stage filtering. This B type variant is intended for medical equipment applications, complying with 1MOP per IEC 60601-1, and features no capacitors to earth for low leakage current.
The filter is chassis mounted with quick connect terminals for easy installation. It has an operating temperature range of -25°C to 100°C and a high potential test voltage of 2500 VAC for 2 seconds between line and earth (B type). The typical MTBF is 3,200,000 hours at 40°C/230 V for B types. The terminal plastic meets UL 94 V-0 flammability rating.
The FN2010B-16-06 is certified to UL 1283, CSA 22.2 No. 8, and IEC/EN 60939 standards, with approvals from CSA, ENEC, and UR. It is suitable for use in power supplies, industrial equipment, and medical devices requiring conducted emission suppression.
| Qty | Low | High |
|---|---|---|
| 1+ | $29.87 | $29.87 |
| 10+ | $26.52 | $26.52 |
| 25+ | $23.80 | $23.80 |
| 60+ | $22.03 | $22.03 |
| 120+ | $21.58 | $21.58 |
| 300+ | $20.92 | $20.92 |
| 540+ | $20.28 | $20.28 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
16 A at 40°C.
250 VAC/DC.
DC to 400 Hz.
Chassis mount.
CSA, ENEC, UR (UL 1283, CSA 22.2 No. 8, IEC/EN 60939).
-25°C to 100°C.
3,200,000 hours for B types at 40°C/230 V.
