FME-210B Schottky diode array with 1 pair common cathode, rated 150V reverse voltage and 10A average rectified current. Packaged in through-hole TO-220F-3.
Mfr Part #:

FME-210B

Available from 1 distributors
Mfr Name: Sanken
Sanken
Schottky diode array with 1 pair common cathode, rated 150V reverse voltage and 10A average rectified current. Packaged in through-hole TO-220F-3.
✓ Total Stock: 2,119 pcs

FME-210B Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Smaxon Electronics ✓
Non-Authorised Inventory information
2,119 pcs
On Request
2119 pcs On Request 1 On Request On Request 11+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

FME-210B Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Current
Diode Configuration
Mounting Type
Operating Temperature
Speed
Supplier Device Package
Technology
Voltage
View Similar Products (0)

FME-210B Description

Short technical summary and product information.

The FME-210B is a Schottky diode array from Sanken, configured as a pair of common cathode diodes. It features a maximum reverse voltage of 150V and an average rectified current of 10A per diode. The forward voltage is typically 900mV at 5A, with a fast recovery time of ≤500ns. The device can handle surge currents up to 100A.



Designed for through-hole mounting, the FME-210B comes in a TO-220-3 Full Pack package (TO-220F-3). It operates over a junction temperature range of -40°C to 150°C and has a thermal resistance of 4°C/W junction to case. Typical applications include high-frequency rectification and power supply circuits requiring efficient switching.



The device is RoHS3 compliant and REACH unaffected. It is suitable for use in industrial and consumer electronics where space and thermal management are important.

FME-210B Quick Information

Product Type: Schottky Diode Array
Series: FME-210B
Canonical Name: Schottky Diode Array 1 Pair Common Cathode 150V 10A Through Hole TO-220F-3
Subcategory: Schottky Diodes

FME-210B Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

FME-210B Features

  • Schottky diode array with common cathode.
  • Rated for 150V reverse voltage and 10A current.
  • Fast recovery time less than 500ns.
  • Low forward voltage drop of 900mV at 5A.
  • Through-hole mounting in TO-220F-3 package.

FME-210B Applications

  • Used in high-frequency rectification circuits.
  • Ideal for power supply output stages.
  • Suitable for freewheeling diode applications.
  • Common cathode configuration simplifies PCB layout.

FME-210B FAQs

7 frequently asked questions generated from this part’s specifications.
What is the maximum reverse voltage of the FME-210B?

150V.

What is the average rectified current rating?

10A.

What is the forward voltage drop?

900mV at 5A.

What is the reverse recovery time?

≤500ns.

What package does the FME-210B come in?

TO-220-3 Full Pack (TO-220F-3).

Is the FME-210B RoHS compliant?

Yes, RoHS3 compliant.

What is the operating temperature range?

-40°C to 150°C junction temperature.
