| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
22 pcs
|
22 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Shielding | |
| Tape & Reel | |
| Temperature Rise | |
| Type | |
| Weight | |
| Width | |
| inductance (Minimum @ At Bias) |
The FIT50-4 from Triad Magnetics is a toroidal inductor engineered to minimize transients and condition output signals by leveling the current waveform. This provides a more stable current supply, making it suitable for high frequency circuits.
This inductor features a minimum inductance of 21.65µH (no bias) and a rated DC current of 4.8A. The maximum DC resistance is 29.2mΩ. It operates within a temperature range of -40°C to 85°C, with an approximate 40°C temperature rise at rated current.
The FIT50-4 has a through-hole mounting type and comes in a radial, vertical (open) package. Its dimensions are 0.700 inches (17.78mm) in length, 0.475 inches (12.07mm) in width, and 0.750 inches (19.05mm) in height. The inductor is unshielded and constructed with an iron powder material.
This component is generally used in differential mode applications or as an output inductor, providing an economical solution for stable current supply in demanding electronic systems.
The minimum inductance of the FIT50-4 is 21.65µH at no bias and 12.27µH at rated DC current.
The FIT50-4 has a rated DC current of 4.8A.
The maximum DC resistance for the FIT50-4 is 29.2mΩ.
The FIT50-4 operates between -40°C and 85°C.
The FIT50-4 is a through-hole component.
The FIT50-4 is a toroidal inductor.
