| Category | |
| Manufacturer Name | |
| Accessory Type | |
| For Use With | |
| Mounting Type | |
| Output Frequency | |
| Package / Case | |
| Rated Current | |
| Weight |
The Enerdoor FIN930.055.M is a common mode choke with very high attenuation, designed to reduce dV/dt and protect motors. It is suitable for applications involving motors controlled by drives, pumps, conveyors, and spindle motors.
This component features a nominal voltage rating of 600V and a rated current of 55A. It operates within an output frequency range of 50 to 3500 Hz and a carrier frequency range of 0 to 16 kHz. The choke provides excellent attenuation and helps in passing immunity and emission tests for IEC61000-6-2 and IEC61000-6-4 standards.
With an IP20 protection rating, the FIN930.055.M is designed for use in a climatic class of -40 to +85°C. It utilizes safety terminal block connectors for secure connections. The choke is engineered to increase motor life and protect against voltage spikes.
Key electrical characteristics include a phase-to-phase potential test voltage of 2400 Vdc (2 sec.) and a phase-to-ground potential test voltage of 3200 Vdc (2 sec.). Overload capabilities include 4x rated current on switch-on, 2x In for 10 seconds, and 1.5 In for 10 minutes. The typical MTBF at 40°C is 250,000 hours.
600V AC/DC
55A
50 to 3500 Hz
-40 to +85°C
IP20
3.5 kg
Chassis mount
