The Enerdoor FIN930.032.M is a common mode choke from the FIN930 series, engineered for motor protection applications. It provides high attenuation to reduce dV/dt, helping to pass immunity and emission tests.
This choke operates with a nominal voltage of 600V and has a rated current of 32A. It features IP20 protection and a climatic class rating of -40 to +85°C, making it suitable for various environmental conditions. The device is designed with safety terminal block connectors for secure connections.
Key benefits include increased motor life and protection against voltage spikes. It is particularly useful for motors controlled by drives, pumps, conveyors, and spindle motors in closed-loop systems. The common mode choke helps improve the overall reliability and performance of motor control systems.
600V.
50 to 3500 Hz.
IP20.
-40 to +85°C.
4x rated current at switch-on, 2x rated current for 10 seconds, and 1.5x rated current for 10 minutes.
177 x 60 x 19 mm and 2.3 kg.
Bulk packaging with screw terminal connections.
