| Category | |
| Manufacturer Name | |
| Accessory Type | |
| For Use With | |
| Mounting Type | |
| Output Frequency | |
| Rated Current | |
| SVHC Present |
The Enerdoor FIN5983.030.M is a high-frequency differential choke engineered for motor protection applications. It operates with a nominal voltage of up to 600V and has a rated current of 30A, with overload capabilities of 2x In for 10 seconds and 1.5x In for 10 minutes.
This choke features terminal block connectors for easy integration and provides excellent attenuation to reduce dV/dt, thereby increasing motor life and protecting against voltage spikes. Its technical specifications include a carrier frequency (PWM) range of 0-16 kHz and low power loss up to 1 kHz output frequency. The device is rated with an IP20 protection level and operates within a climatic class of -40°C to +85°C.
Applications for the FIN5983.030.M include motors controlled by drives, woodworking machinery, and closed-loop motor control systems. It is designed to enhance the reliability and longevity of motor systems by mitigating electrical stresses.
The nominal voltage is 600V.
The rated current is 30A.
The output frequency range is 0 to 1000 Hz.
The IP protection rating is IP20.
The climatic class is -40°C to +85°C.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
