| Category | |
| Manufacturer Name | |
| Accessory Type | |
| For Use With | |
| Mounting Type | |
| Output Frequency | |
| Package / Case | |
| Rated Current | |
| Termination Style |
The Enerdoor FIN5955.006.M is a high-frequency differential choke with excellent attenuation capabilities, designed to reduce dV/dt and protect motors. It features a nominal voltage rating of 600V and a rated current of 6A, with an output frequency range of 0-250 Hz. The choke is built with safety terminal block connectors for secure connections and offers IP20 protection.
This component is suitable for applications involving AC motors controlled by VFDs, high-speed motors up to 250 Hz, and is particularly useful in woodworking machinery and spindle motor closed-loop systems. Its compact design and low power loss make it an efficient choice for motor protection, increasing motor life and safeguarding against voltage spikes.
Key electrical characteristics include a potential test voltage of 2400 Vdc phase-to-phase and 3200 Vdc phase-to-ground. The climatic class is rated for -40°C to +85°C, with an MTBF of 250,000 hours at 40°C. The saturation current is rated at 4 times the rated current when the switch is ON.
600V AC/DC.
-40 to +85°C.
CASE 1.
IP20.
24A (4 times the rated current).
250,000 hours at 40°C.
2.4W.
