| Category | |
| Manufacturer Name | |
| Accessory Type | |
| For Use With | |
| Output Power | |
| Weight |
The Fulham FHEZ10A24 is a 24-inch emergency exit light designed for universal mounting within T-Grid ceiling systems. This unit provides reliable emergency illumination, operating for a minimum of 90 minutes on its integrated Ni-Cd battery after a power failure. It features a universal input voltage range of 120-277VAC and consumes a nominal 5.7W, with an output power of 10.7W during emergency mode.
This emergency exit light delivers 1300 lumens at 5000K color temperature and 80 CRI, ensuring clear visibility. The protective lens is made of 1.2mm frosted polycarbonate with a V-0 flame rating. The housing is constructed from steel, and the overall dimensions are 23.9" L x 1.02" W x 1.86" H. It is suitable for dry and damp locations and includes a 5-year warranty.
The FHEZ10A24 is powered by the FHSCP EM driver and is CEC compliant. It also features surge protection per C62.41 (TVS) and an integrated test switch for easy maintenance. Lumen maintenance is rated at L70 >60,000 hours and L90 >40,000 hours.
The Fulham FHEZ10A24 operates on a universal input voltage range of 120-277VAC.
The FHEZ10A24 provides a minimum of 90 minutes of emergency operation on its Ni-Cd battery.
The FHEZ10A24 has a maximum lumen output of 1300 lumens at a color temperature of 5000K and 80 CRI.
The overall size of the FHEZ10A24 is 23.9 inches long by 1.02 inches wide by 1.86 inches high.
The Fulham FHEZ10A24 comes with a 5-year warranty from the date of manufacture.
The EM driver has an operating temperature range of 0°C to 50°C.
The maximum module case temperature (Tc) is 90°C.
