| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Material | |
| Cable End Type | |
| Connector | |
| Contact Finish | |
| Contact Material | |
| Contact Resistance | |
| Current Rating | |
| Durability (Mating Cycles) | |
| FFC, FCB Thickness | |
| Features | |
| Flat Flex Type | |
| Halogen Free | |
| Height Above Board | |
| Housing Material | |
| Insulation Resistance | |
| Lead Spacing | |
| Lead Style | |
| Locking Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Operating Humidity | |
| Operating Temperature | |
| Packaging Type | |
| Pitch | |
| SVHC Present | |
| Standard Package Quantity | |
| Storage Temperature | |
| Tape & Reel | |
| Termination | |
| Voltage Rating | |
| Withstanding Voltage |
The Hirose FH41-68S-0.5SH(05) is a 68 position FFC connector from the FH41 series, featuring a 0.5mm pitch and right angle surface mount orientation. It is designed for use with tabbed FFC cables of 0.30mm thickness. The connector includes a flip lock and backlock mechanism for secure cable retention, and solder retention features for reliable board attachment.
Electrical specifications include a voltage rating of 50V, current rating of 0.5A per contact, contact resistance of 100mΩ maximum, insulation resistance of 500MΩ minimum, and withstanding voltage of AC 150Vrms for 1 minute. The operating temperature range is -40°C to 105°C.
The housing and actuator are made of halogen-free liquid crystal polymer (LCP) with UL94 V-0 flammability rating. Contacts are phosphor bronze with gold finish. The connector is supplied in tape and reel packaging with 2500 pieces per reel, suitable for automatic pick-and-place assembly.
| Qty | Low | High |
|---|---|---|
| 2,500+ | $1.59 | $1.59 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
68 positions.
0.50mm (0.020").
50V.
0.5A.
Surface mount, right angle.
-40°C to 105°C.
Flip lock and backlock.
